VideoView介绍
之前介绍过使用MediaPlayer SurfaceView实现播放视频功能。无意间发现官方封装了VideoView组件来实现简单视频播放功能，内部同样是使用MediaPlayer SurfaceView的形式控制MediaPlayer对视频文件进行播放。使用场景比较简单，适用于只是播放视频的场景，其提供能力有限不太适合使用在调节视频亮度等其他功能。
MediaController
除了播放组件VideoView外还有MediaController组件为视频播放提供播放操作栏功能，可支持视频播放、暂停、快进、快退等功能。另外还提供进度条功能可以拖拽到指定位置进行播放视频。
使用
VideoView封装了MediaPlayer同样也提供了类似于MediaPlayer的api。例如start方法同样是播放视频功能，但调用该方法前最好也是通过设置setOnpreparedListener回调结果来执行，当调用setVideoPath后会主动执行prepareAsync方法。在VideoView内部帮助开发者封装实现了很多功能，其实也能借鉴其内部源码来实现功能更全面功能更完备的自制播放器。
| 常用Api | 说明 |
|---|---|
| setVideoPath | 设置视频资源 |
| start | 播放 |
| pause | 暂停 |
| resume | 重播 |
| seekTo | 指定位置播放 |
| isPlaying | 视频是否播放 |
| getCurrentPosition | 获取当前播放位置 |
| setMediaController | 设置MediaController |
| setOnpreparedListener | 监听视频装载完成事件 |
// 实例化videoView
videoView = new VideoView(this);
Uri uri = Uri.fromFile(new File("sdcard/DCIM","新世纪福音战士24.mp4"));
//加载视频资源
videoView.setVideoURI(uri);
LinearLayout linearLayout = new LinearLayout(this);
linearLayout.addView(videoView);
setContentView(linearLayout);
//设置监听
videoView.setOnPreparedListener(new MediaPlayer.OnPreparedListener() {
@Override
public void onPrepared(MediaPlayer mp) {
//回调成功并播放视频
videoView.start();
}
});
//创建操作栏
MediaController mediaController = new MediaController(this);
videoView.setMediaController(mediaController);
mediaController.setMediaPlayer(videoView);
源码分析
既然封装了VideoView和MediaController两者组件，在使用过程中也发现了许多之前尝试实现的一些功能看看他们又是如何实现的。
进度显示
MediaController显示时调用show方法内部可以看到一个post(mShowProgress);方法
public void show(int timeout) {
if (!mShowing && mAnchor != null) {
setProgress();
if (mPauseButton != null) {
mPauseButton.requestFocus();
}
disableUnsupportedButtons();
updateFloatingWindowLayout();
mWindowManager.addView(mDecor, mDecorLayoutParams);
mShowing = true;
}
updatePausePlay();
// cause the progress bar to be updated even if mShowing
// was already true. This happens, for example, if we're
// paused with the progress bar showing the user hits play.
post(mShowProgress);
if (timeout != 0 && !mAccessibilityManager.isTouchExplorationEnabled()) {
removeCallbacks(mFadeOut);
postDelayed(mFadeOut, timeout);
}
}可以看到mShowProgress是一个Runnable，内部会延迟不停调用自己来更新setProgress()。setProgress()方法就是读取MediaPlayer播放进度从而更新播放信息。
private final Runnable mShowProgress = new Runnable() {
@Override
public void run() {
int pos = setProgress();
if (!mDragging && mShowing && mPlayer.isPlaying()) {
postDelayed(mShowProgress, 1000 - (pos % 1000));
}
}
};播放尺寸适配
之前自定义实现播放尺寸适配，在VideoView内部直接帮助开发者实现视频播放适配，详细代码可以直接看onMeasure重写。代码大致算法就是通过比较VideoView布局宽高和视频的宽高进行比例比较来重写计算VideoView的宽高。
protected void onMeasure(int widthMeasureSpec, int heightMeasureSpec) {
//Log.i("@@@@", "onMeasure(" MeasureSpec.toString(widthMeasureSpec) ", "
// MeasureSpec.toString(heightMeasureSpec) ")");
int width = getDefaultSize(mVideoWidth, widthMeasureSpec);
int height = getDefaultSize(mVideoHeight, heightMeasureSpec);
if (mVideoWidth > 0 && mVideoHeight > 0) {
int widthSpecMode = MeasureSpec.getMode(widthMeasureSpec);
int widthSpecSize = MeasureSpec.getSize(widthMeasureSpec);
int heightSpecMode = MeasureSpec.getMode(heightMeasureSpec);
int heightSpecSize = MeasureSpec.getSize(heightMeasureSpec);
if (widthSpecMode == MeasureSpec.EXACTLY && heightSpecMode == MeasureSpec.EXACTLY) {
// the size is fixed
width = widthSpecSize;
height = heightSpecSize;
// for compatibility, we adjust size based on aspect ratio
if ( mVideoWidth * height < width * mVideoHeight ) {
//Log.i("@@@", "image too wide, correcting");
width = height * mVideoWidth / mVideoHeight;
} else if ( mVideoWidth * height > width * mVideoHeight ) {
//Log.i("@@@", "image too tall, correcting");
height = width * mVideoHeight / mVideoWidth;
}
} else if (widthSpecMode == MeasureSpec.EXACTLY) {
// only the width is fixed, adjust the height to match aspect ratio if possible
width = widthSpecSize;
height = width * mVideoHeight / mVideoWidth;
if (heightSpecMode == MeasureSpec.AT_MOST && height > heightSpecSize) {
// couldn't match aspect ratio within the constraints
height = heightSpecSize;
}
} else if (heightSpecMode == MeasureSpec.EXACTLY) {
// only the height is fixed, adjust the width to match aspect ratio if possible
height = heightSpecSize;
width = height * mVideoWidth / mVideoHeight;
if (widthSpecMode == MeasureSpec.AT_MOST && width > widthSpecSize) {
// couldn't match aspect ratio within the constraints
width = widthSpecSize;
}
} else {
// neither the width nor the height are fixed, try to use actual video size
width = mVideoWidth;
height = mVideoHeight;
if (heightSpecMode == MeasureSpec.AT_MOST && height > heightSpecSize) {
// too tall, decrease both width and height
height = heightSpecSize;
width = height * mVideoWidth / mVideoHeight;
}
if (widthSpecMode == MeasureSpec.AT_MOST && width > widthSpecSize) {
// too wide, decrease both width and height
width = widthSpecSize;
height = width * mVideoHeight / mVideoWidth;
}
}
} else {
// no size yet, just adopt the given spec sizes
}
setMeasuredDimension(width, height);
}到此这篇关于Android音视频开发之VideoView使用指南的文章就介绍到这了,更多相关Android VideoView内容请搜索Devmax以前的文章或继续浏览下面的相关文章希望大家以后多多支持Devmax！
