ImageSwitcher图像切换器的使用实例

<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
  xmlns:tools="http://schemas.android.com/tools"
  android:id="@ id/LinearLayout1"
  android:layout_width="match_parent"
  android:layout_height="match_parent"
  android:background="@drawable/bg67"
  android:orientation="vertical"
  android:paddingBottom="@dimen/activity_vertical_margin"
  android:paddingLeft="@dimen/activity_horizontal_margin"
  android:paddingRight="@dimen/activity_horizontal_margin"
  android:paddingTop="@dimen/activity_vertical_margin"
  tools:context=".MainActivity" >

  <TextView
    android:id="@ id/show"
    android:layout_width="fill_parent"
    android:layout_height="wrap_content"
    android:layout_marginLeft="20dp"
    android:layout_marginTop="20dp"
    android:text="我是当前图片的信息~"
    android:textSize="24dp" />


  <LinearLayout
    android:layout_width="match_parent"
    android:layout_height="wrap_content"
    android:orientation="vertical">

    <ImageSwitcher
      android:layout_width="wrap_content"
      android:layout_height="wrap_content"
      android:id="@ id/image"
      android:layout_gravity="center"
      android:background="#666666">
    </ImageSwitcher>

    <LinearLayout
      android:layout_width="match_parent"
      android:layout_height="wrap_content"
      android:orientation="horizontal"
      android:gravity="center">

      <Button
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="上一张"
        android:layout_marginLeft="20dp"
        android:textSize="24dp"
        android:id="@ id/up" />

      <Button
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:text="下一张"
        android:layout_marginLeft="20dp"
        android:textSize="24dp"
        android:id="@ id/down" />

    </LinearLayout>

  </LinearLayout>
</LinearLayout>

package com.example.imageswitchdemo;

import android.os.Bundle;
import android.app.Activity;
import android.view.Menu;
import android.view.View;
import android.view.View.OnClickListener;
import android.view.animation.Animation;
import android.view.animation.AnimationUtils;
import android.widget.Button;
import android.widget.ImageSwitcher;
import android.widget.ImageView;
import android.widget.TextView;
import android.widget.ViewSwitcher.ViewFactory;

public class MainActivity extends Activity
{
  TextView show=null;
  Button up,dowm=null;
  ImageSwitcher image=null;
  private int[] images=new int[]{R.drawable.a001,R.drawable.a002,R.drawable.a003,
                  R.drawable.a004,R.drawable.a005,R.drawable.a006,
                  R.drawable.a007,R.drawable.a008,R.drawable.a009};
  private int index=0;

  @Override
  protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_main);

    //获取控件
    show=(TextView) findViewById(R.id.show);
    up=(Button) findViewById(R.id.up);
    dowm=(Button) findViewById(R.id.down);
    image=(ImageSwitcher) findViewById(R.id.image);

    //为获取到的控件添加显示效果:淡入动画和淡出动画
    image.setInAnimation(AnimationUtils.loadAnimation(this, android.R.anim.fade_in));
    image.setOutAnimation(AnimationUtils.loadAnimation(this, android.R.anim.fade_out));

    //为图像切换器设置一个ViewFactory，并重写makeView方法
    image.setFactory(new ViewFactory()
    {

      @Override
      public View makeView()
      {
        //指定视图切换工程
        return new ImageView(MainActivity.this);
      }
    });
    image.setImageResource(images[index]);
    show.setText("一共有" images.length "张图片，当前是第" (index 1) "张图片");

    //当点击按钮时，图像切换并显示相应的信息
    up.setOnClickListener(new OnClickListener()
    {

      @Override
      public void onClick(View arg0)
      {
        if(index>0)
          index--;
        else
          index=images.length-1;

        image.setImageResource(images[index]);
        show.setText("一共有" images.length "张图片，当前是第" (index 1) "张图片");
      }
    });

    //同理，当点击按钮时，图像切换并显示相应的信息
    dowm.setOnClickListener(new OnClickListener()
    {
      public void onClick(View arg0)
      {
        if(index<images.length-1)
          index  ;
        else
          index=0;

        image.setImageResource(images[index]);
        show.setText("一共有" images.length "张图片，当前是第" (index 1) "张图片");
      }
    });
  }

  @Override
  public boolean onCreateOptionsMenu(Menu menu) {
    // Inflate the menu; this adds items to the action bar if it is present.
    getMenuInflater().inflate(R.menu.main, menu);
    return true;
  }

}
