echarts柱状图背景重叠组合而非并列的实现代码

// base64位背景图 此处可以改为相对路径 var barImage = './img/chart_bg.png';
// 在线上转base64位工具 https://www.sojson.com/image2base64.html
var PatternImgA = new Image();
PatternImgA.src = barImage;

 series: [
 {
     type: 'bar',
     data: arr,
     barWidth: 16,
     barCategoryGap: 23,
     margin: [0, 0, 0, 16],
     itemStyle: {
     	 //渐变色，也可以直接用数组给不同的柱子设置不同的颜色
       color: function (params) {
         return colorList[params.dataIndex];
       },
       barBorderRadius: [16, 16, 0, 0],
     },
     label: {
       show: true,
       fontSize: 12,
       position: 'top',
       color: '#AAAAAA',
     }
   },
   {
   	 //这里设置包含关系，只需要这一句话
     barGap: "-100%",
     type: 'bar',
     data: arr,
     barWidth: 16,
     barCategoryGap: 23,
     itemStyle: {
     	 //此处引入条纹背景
       color: { image: PatternImgA, repeat: 'repeat' },
       barBorderRadius: [16, 16, 0, 0],
       xAxisIndex: 2,
       yAxisIndex: 2,
       zlevel: 2
     }
   }
 ]
